ASX SERIES


SCREW-ON INSERT TYPE MILLING CUTTER


ASX400 ARBOR

Low resistance 3D curved cutting edge

High rigidity holder

Economical use of 4 cutting edges

  • Cutter Diameter: Ø2.000" | Ø10.000"

  • APMX: 0.394"


ASX400 SHANK

Low resistance 3D curved cutting edge

High rigidity holder

Economical use of 4 cutting edges

  • Cutter Diameter:Ø1.250" | Ø2.000"

  • APMX: 0.394"


ASX400 SCREW-IN

Low resistance 3D curved cutting edge

High rigidity holder

Economical use of 4 cutting edges

  • Cutter Diameter: Ø32 mm | Ø40 mm

  • APMX: 0.394"


ASX445 ARBOR

High rigidity due to carbide shim

​A wide range of chip breakers.

Precise molded type 20° positive insert

  • Cutter Diameter: Ø2.500" | Ø10.000"

  • APMX: 0.236"


ASX445 SHANK

High rigidity due to carbide shim

​A wide range of chip breakers.

Precise molded type 20° positive insert

  • Cutter Diameter: Ø50 mm | Ø63 mm
    Ø80 mm

  • APMX: 6 mm
